Plastic Small Animal Veterinary Anesthesia Breathing Support System

Name: Plastic Small Animal Veterinary Anesthesia Breathing Support System
Brand: INTELLVET
Price: 1 USD

Quality Plastic Small Animal Veterinary Anesthesia Breathing Support System for sale

Place of Origin : Beijing, China

Brand Name : INTELLVET

Model Number : SV-3000

Power Source : Electric

Warranty : 1 Year

After-sale Service : Free spare parts

Material : Plastic

Shelf Life : 1years

Quality Certification : ce

Instrument classification : Class II

Safety standard : None

Type : Washing,Ventilation & Vacuum Apparatus

Certification : ce

Supply Ability : 200 Set/Sets per Month

MOQ : 1 set

Packaging Details : carton package plus thick sponge

Contact Now

About Us:

Beijing Intelligent Technology Co., Ltd, based in Daxing Bio-pharmaceutical zone and with registration capital of 50 Million RMB, is a company focus on R & D, Designning and Selling veterinary medical equipment. We continously provide high quality and reliable veterinary medical equipment to animal hospitals, veterinary medical training schools and institutions, labs and etc. We also provide medical solution integration to all oru customers to simplify the purchasing process, save time & money and enhance working efficiency of our customers.

Founded in 2012, we started our business from representing American high-end vet medical equipment. Contribute to the stable performance and professional service, Intelligent company gained good customer reputation. The two large clinical bases helps us to provide more and more data support to make our equipment meet different surgeon's surgery demand.

We strong believe that " Quality Creats Classic, Professional Creates Value"

Plastic Small Animal Veterinary Anesthesia Breathing Support System

Basic Technical Parameters of SV-3000 Veterinary Anesthesia Ventilator:

Basic description
Parameter		Description
Display		8 " TFT, with touch screen.
Drive gas	Gas type	O2 or Air
	Inlet pressure	280-600 kPa.
	Max flow	≤ 120 L / min.
Operating Mode		VCV,PCV,SIMV-VC,SIMV-PC,PSV,Manual/SPONT. Optional: SIMV-PRVC, PRVC
Waveform		Waveform: Pressure,Flow-rate,Volume,CO2(optional),Pleth(optional) Loop:PV loop, PF loop,FV loop
Safety Pressure		System pressure does not exceed 10 KPa.
Battery Type		Li-ion,work time more than 3 hours

Parameters setting range
Parameter	description
Tidal volume	Range: 50 - 1500ml; optional 10 - 1500ml Increment: 10 ~ 100 mL: 5mL; 100 ~ 1500 mL: 10mL;
Respiratory rate	Range: 1 ~ 100 bpm; increment: 1 bpm.
Inspiratory time	Range: 0.1 ~ 10.0 s; increments: 0.1 s.
Respiratory ratio	Range: 4:1 to 1:10; increments: 0.5.
Percentage of inspiratory pause	Range: 0 to 50%; Increment: 5%
PEEP	Range: OFF, 3 ~ 20 cmH2O; Increment: 1 cmH2O.
Pressure Support	Range: 0 ~ 70 cmH2O; Increment: 1 cmH2O.
Pressure Control	Range: 5 ~ 70 cmH2O; Increment: 1 cmH2O.
Flow trigger	Range: 0.5 ~ 20L/min; increments: 0.1L/min.
Pressure Trigger	Range: 0 ~ 20 cmH2O; increments: 0.1 cmH2O.
PSV Insp Termination Level	Range: 5 ~ 80%; increments: 5%.

monitored parameters
Parameter	Description
Inspiratory tidal volume	Range: 0 ~ 2500 mL; Resolution: 1 mL. Error of ± 20mL or actual value ± 15%, which ever is greater
Expiratory tidal volume	Range: 0 ~ 2500 mL; Resolution: 1 mL. Error of ± 20mL or actual value ± 15%, which ever is greater
Minute ventilation	Range: 0 ~ 60 L / min; Resolution: 0.1 L / min. Error of ± 1L/min or actual value ± 15%, which ever is greater
Spontaneous minute ventilation	Range: 0 ~ 60 L / min; Resolution: 0.1 L / min. Error of ± 1L/min or actual value ± 15%, which ever is greater
Respiratory rate	Range: 0 ~ 100 bpm; Resolution: 1 bpm. Error of ± 2 beats / min or actual value ± 10%, which ever is greater
Spontaneous breathing frequency	Range: 0 ~ 100 bpm; Resolution: 1 bpm. Error of ± 2 beats / min or actual value ± 10%, which ever is greater
Respiratory ratio	Range: 30:1 to 1:150; resolution: 0.1. Error of ± 20%,
Peak airway pressure	Range: 0 ~ 100 cmH2O; Resolution: 1 cmH2O. Error of ± (2% + 4% of full scale actual reading)
Mean airway pressure	Range: 0 ~ 100 cmH2O; Resolution: 1 cmH2O. Error of ± (2% + 4% of full scale actual reading)
PEEP	Range: 0 ~ 100 cmH2O; Resolution: 1 cmH2O. Error of ± (2% + 4% of full scale actual reading)
Inspiratory plateau pressure	Range: 0 ~ 100 cmH2O; Resolution: 1 cmH2O. Error of ± (2% + 4% of full scale actual reading)
FiO2(optional)	Range: 15 to 100%; Resolution: 1%. Error is ± (2.5% +2.5% of full scale actual reading)
Compliance	Range: 0 ~ 300 mL/cmH2O; resolution: 1 mL/cmH2O. Error of ± 20% or ± 5 mL/cmH2O, which ever is greater
Airway resistance	Range: 0 ~ 600 cmH2O / (L / S); Resolution: 1 cmH2O / (L / S). Error of ± 20% or ± 5 cmH2O, which ever is greater
EtCO2 (optional)	Range: 0 ~ 100 mmHg; Resolution: 1 mmHg. Error is ± (0.43% of the volume percentage + 8% of the gas concentration) is equivalent to the range of optional units to monitor KPa and mmHg.
Inhalation of carbon dioxide (optional)	Range: 0 ~ 100mmHg; Resolution: 1 mmHg. Error is ± (0.43% of the volume percentage + 8% of the gas concentration) is equivalent to the range of optional units to monitor KPa and mmHg.
MAC values(optional)	Range: 0 to 10; resolution: 0.01

Why Choose us as your partner:

We are real manufacturer of vet anesthesia machine, we can guarantee all the equipment you order from us with reliable technical support and fast shippment;
Competitive price: we never promise the cheapest price because we believe that " Price consistent with Quality", but we will promise the most copetitive price.
Reliable and Stable performance: Based on more than 5 years' experience in vet medical sector and American origined technology and each equipment are strictly tested before shippment arranged.
Fast shippment: for regular orders, we will arrange shippment as soon as your payment reached because we have enough finished equipment & spare parts in stock

Shipping Terms:

DHL, UPS, FEDEX, TNT and etc. , door to door
Air cargo delivery

Plastic Small Animal Veterinary Anesthesia Breathing Support System
